2100 & 2200 Series
Patio Slider
The 2100 and 2200 series patio sliders come standard with a 5 1/4" frame depth and standard 12psf rated water resistant sill. Designed to maximize interior and exterior space yet allow for horizontal ventilation and passage, these doors slide on tandem stainless-steel rollers for ease of operation. Common configurations include XO, OX, OXO, and OXXO (O = Stationary, X = Operable). The 2200 series is identical to the 2100 series with the exception of the increased structural reinforcement at the interlocking rail of the operating sash, yielding a better wind loading system.
2100 Product Features
- Exterior Sliding Patio Door
- XO, OX, OXO, and OXXO Configurations
- 5 1/4" Frame Depth
- 3 1/2" Interlocking Sightline
- Architectural Grade AW40
- Standard 12psf Water Resistant Sill
- Pour & Debridged Thermal Break
- Standard 1” Glazing
- Factory Glazed for Added Quality Control
- Tandem Stainless Steel Rollers
- Anodized and AAMA 2605 Paint Finishes
2200 Product Features
- Exterior Sliding Patio Door
- XO, OX, OXO, and OXXO Configurations
- 5 1/4" Frame Depth
- 3 1/2" Interlocking Sightline
- Architectural Grade AW60
- Reinforced Interlocking Jamb Rail on Operating Sash for Higher Wind Loads
- Standard 12psf Water Resistant Sill
- Pour & Debridged Thermal Break
- Standard 1” Glazing
- Factory Glazed for Added Quality Control
- Tandem Stainless Steel Rollers
- Anodized and AAMA 2605 Paint Finishes
